TEAM,

Terlampir buildbook untuk BAYER. Tolong di-note & di-ikuti

Please find attached the build book for device configurations, as there's no
space for staging in Tangerang and Surabaya at Bayer sites, device has to be
configured at PTM's warehouse.

Note: Devices have to be delivered to Bayer's premises for Tangerang and
Surabaya before 26th Jan 2024. Onsite deployment will start on 30th Jan 2024
(dates and time to be confirmed).

Hostnames below to configure with each devices, during device
configurations, please revert back Serial Numbers and MAC Addresses to me,
so that IP Addresses can be reserved before onsite deployment.

Site Code

site name

Building

Floor

Room

Ricoh model

New Hostname

New Serial Number

New MAC Address

SBA1

Surabaya

C301-Logistic Office

1st Floor

SBA1/C301

IMC300F

WIDD000013

SBA1

Surabaya

B201-Production Office

1st Floor

SBA1/B201

IMC300F

WIDD000014

SBA1

Surabaya

A201-SGC Office

1st Floor

SBA1/A201

IMC300F

WIDD000015

SBA1

Surabaya

B201-QA Office

2nd Floor

SBA1/B201

IMC300F

 WIDD000016

SBA1

Surabaya

B201- Main Office

2nd Floor

SBA1/B201

IMC3010

 WIDD000017

SBA1

Surabaya

C305-Engineering

2nd Floor

SBA1/C305

IMC300F

 WIDD000018

SBA1

Surabaya

RK9-Office WH RK9

2nd Floor

SBA1/RK9

IMC300F

 WIDD000019

TNG1

Tangerang

Main Office building

2nd Floor

Main office

IMC3010

WIDD000020

TNG1

Tangerang

Engineering & Packaging Office

1st Floor

Packaging Office

IMC300F

WIDD000021

TNG1

Tangerang

QC Lab Office

1st Floor

QC Lab Office

IMC300F

 WIDD000022

Things to note on device configurations:

1.	Configurations must be on point.
2.	Hostnames provided on table above.
3.	Attached additional instruction for Creating Device Certificate.
4.	Attached the Root Certificate ZIP file (unzip before uploading to
machine).

a.	Activate root certificate.
b.	Security -> Site Certificate -> Site Certificate Check: inactive

5.	Device label, refer to attached.

Deployment onsite (date / time to be confirmed):

1.	Configure card readers onsite.
2.	Work on 1 device at a time, disconnect old device and connect new
device.
3.	Validate DHCP IP.
4.	ATOS to push LRS software.
5.	LRS Testing.

Thank you.
